Saddle Roof Solar Mounting System

The saddle roof solar mounting system is primarily designed for industrial plants, warehouses, and other large-span buildings with wave-shaped roofs, enabling efficient utilization of the undulating roof space. This mounting system is secured directly to the peaks or troughs of the saddle roof using specialized clamps, eliminating the need for drilling. This approach not only protects the roof’s waterproof layer but also simplifies the installation process, making it particularly suitable for scenarios requiring rapid deployment.

Installation site

  • Open Ground

Installation Angle

  • 5-45°

PV Module

  • Framed or unframed

Module layout

  • Vertical or horizontal

Max wind speed

  • 45m/s

Color

  • Silver Gray

Material

  • prestressed concrete pile& ≥275g/m^2 Zinc Aluminum Magnesium DX51D/S350GD steel or ≥65um hot dip galvanized Q235B/Q355B steel

Warranty

  • 10 years

Standards

  • BS6399,JISC 8955,Eurocode 1,DIN1055,AS/NZS 1170 and other standards

Product Introduction

The materials used, such as galvanized steel and galvanized aluminum-magnesium, offer excellent corrosion resistance and anti-aging properties, ensuring long-term durability against environmental factors like rain and UV exposure. This guarantees the system’s stability under complex climatic conditions. The mounting structure is lightweight yet high in strength, capable of withstanding external loads such as strong winds and snow, while minimizing additional pressure on the roof.

The design is flexible, allowing for tilt angle adjustments based on the roof’s shape and sunlight conditions to maximize power generation efficiency. Economical and practical, this system features low installation and maintenance costs, making full use of the unique structure of saddle roofs. It is a reliable choice for solar mounting systems on industrial building rooftops.

Component
